Three Piece Ball Valve
- Home
- Ball Valve
- Three Piece Ball Valve
Our Products
Brochures
Technical Specifications
| Specification | Details |
| Size Range | 15 mm to 600 mm |
| Pressure Rating | Class 150 to 2500 |
| Design Standard | EN ISO 17292, API 6D |
| Materials | Carbon Steel, Stainless Steel, Duplex Steel |
| Seat Materials | PTFE, RPTFE, Metallic |
| End Connections | Flanged, Screwed, Welded |
| Operation | Lever / Gear Operated |
Three Piece Ball Valve
Built for applications where maintenance accessibility is important, the Three Piece Ball Valve offers convenient inline servicing without disturbing pipeline connections. Its sturdy three-piece construction delivers dependable shut-off performance, smooth media handling, and reduced downtime in demanding process systems. Widely preferred in chemical plants, water systems, pharmaceuticals, and industrial processing units.
Key Features
- Easy dismantling for maintenance
- Reliable sealing performance
- Full flow with minimal pressure loss
- Strong body construction
- Suitable for high-temperature & pressure service
- Corrosion-resistant material options
Technical Specifications
| Specification | Details |
| Size Range | 15 mm to 600 mm |
| Pressure Rating | Class 150 to 2500 |
| Design Standard | EN ISO 17292, API 6D |
| Materials | Carbon Steel, Stainless Steel, Duplex Steel |
| Seat Materials | PTFE, RPTFE, Metallic |
| End Connections | Flanged, Screwed, Welded |
| Operation | Lever / Gear Operated |
Three Piece Ball Valve
Technical Specifications
| Specification | Details |
| Size Range | 15 mm to 600 mm |
| Pressure Rating | Class 150 to 2500 |
| Design Standard | EN ISO 17292, API 6D |
| Materials | Carbon Steel, Stainless Steel, Duplex Steel |
| Seat Materials | PTFE, RPTFE, Metallic |
| End Connections | Flanged, Screwed, Welded |
| Operation | Lever / Gear Operated |
